Operational Amplifiers & Linear Integrated Circuits: Theory and Application

Now in its third edition, Operational Amplifiers & Linear Integrated Circuits offers an extensive and detailed exploration of the modern op amp and associated specialized linear integrated circuits. The exploration begins with a fundamental building building block, the differential amplifier. The decibel, Bode plots and negative feedback concepts are introduced. The theory of basic amplifier circuits is presented along with applications. Practical performance aspects such as frequency response, slew rate, offset, drift and noise are presented. Chapters are dedicated to specialized devices and applications such linear and switching regulator, non-linear amplifiers, oscillators and function generators, active filters, and AD and DA conversion. Circuit simulations are integrated throughout the chapters. Each of the twelve chapters includes a list of learning outcomes, a summary, review questions and a large number of exercises grouped in terms of Analysis, Design, Challenge and Computer Simulation. Appendices include the answers to the odd-numbered exercises. This is the Kindle print replica version of the on-line OER. The current revision number and date are version 3.2.11, 16 October 2024.
